| Frequency Ranges |
136-174MHz , 400 - 480MHz , 430 - 520MHz
PMR446MHz |
| Channel Numbers |
16 |
| Openating Mode |
Co-channel or Dis-channel Simplex |
| Output Power |
UHF H:6W , L:1W
VHF H:8W , L:1W
PMR 0.5W |
| Voltage |
7.4 VDC |
|
| Working Temperature |
-30℃ ~ +60℃ |
| Modulation Type |
FM (F3E) |
| Max Frequency Deviation |
≤±5KHz |
| Frequency Stability |
±5PPM |
| Sensitivity (12dB SINAD) |
≤0.2µV |
| Audio Output Power |
≥500mW |
| Spurious Radiation |
< -60dB |
| Weight |
320 G |
| Dimension |
128 x 53 x 31 MM |
|
