| General |
| Frequency Range |
400-470MHz |
| Channel Spacing |
Digital : 12.5KHz |
| Channel Number |
1000 |
| Standard Package |
2000mAh , Lithium-ion |
| Working Temperature |
-20℃～+50℃ |
| Storage Temperature |
-40℃～+80℃ |
| Working Voltage |
7.4VDC |
| Working Currency |
< 1300mA |
|
| Receiver |
| Frequency Stability |
±2.5ppm |
| Inter-modulation |
65dB |
| Co-channel Rejection |
-8dB@12.5KHz |
| Spurious Inhibition |
-57dBm@<1GHz , -47dBm@>1GHz |
| Block |
84dB |
| Adjacent Channel Selectivity |
60dB@12.5KHz |
| Spurious Response |
≥70dB |
| Regulated Audio Power |
1W |
| Digital Sensitivity |
0.3µV / -117.4dBm(BER 5%)
0.7µV / -110dBm(BER 1%) |
|
